Lectrosonics RPS4 Redundant DC Power Supply

Lectrosonics RPS4 Redundant DC Power Supply Lectrosonics RPS4 Redundant DC Power Supply
With $99 Purchase »
Your Price: $2,259.00
List Price: $3,047.00

Availability: Out of Stock
Quantity:
Manufacturer:

Sales SKU: LECRPS4
Product Code: RPS4

The Lectrosonics RPS4 provides a highly reliable DC power source for low voltage devices such as wireless microphone receivers, IFB transmitters and audio signal processing equipment. Two internal power supplies and two temperature controlled fans operate in a failover mode for an automatic backup in the event one of them fails.

The 1RU chassis eliminates the need for a separate power strip with individual "wall warts" or "boa style" power supplies for each low voltage device. Power cables from the RPS4 to the devices can be securely routed to prevent inadvertent disconnects and free up space on power strips in the equipment rack. The DC power connectors are a threaded, locking type for reliability. The RPS4 ships with two 12-inch and two 18-inch DC supply cables.

Lectrosonics RPS4 - Features:

  • Dual power supplies for fail-over operation
  • Four 12VDC 1.5A outputs
  • Dual cooling fans - temperature controlled
  • 2A automotive type blade fuses
  • Locking coaxial DC power connectors
  • LED indicators blink red during fault
  • Spare fuse holder on rear panel
  • Input Voltage Range: 100 to 240 VAC; 50/60 Hz
  • Overall Power Consumption: 100W
  • Outputs: Four 12VDC; 1.5A
  • Output Fuses: Individual 2A automotive blade type
  • Temperature Range: -4° to +122° F | -20° to +50° C
  • Output DC Ripple: < 20 mV
