PSC FCPII Cart Power II Power Distribution Unit

PSC FCPII Cart Power II Power Distribution Unit PSC FCPII Cart Power II Power Distribution Unit
With $75 Purchase »
Your Price: $657.00
List Price: $691.50

Availability: Usually Ships In 7 - 14 days
Quantity:
Manufacturer:

Sales SKU: PSCCRTPWR2
Product Code: FCPII

This PSC Cart Power II offers a convenient way to distribute DC power to all of the equipment on your small sound cart or your entire digital audio recording package. It can be operated from world-wide AC power without adjustment and will provide up to 10 amps of DC current to power your equipment. In addition, the Cart Power II contains an external battery input which will allow you to operate from battery power. You can also operate it on both AC power and battery power at the same time. In this case, the unit becomes an un-interruptible power source. It will operate from AC power as long as the AC power is available. If the AC power gets cut off, the unit will automatically switch over to battery power in a seamless and quiet manner.

Each output of the PSC Cart Power II contains a PSC Quiet Power Technology™ filter designed to block inter-modulation noise sources common in today's equipment. Additionally, each output is individually protected against short circuits through the use of automatically resetting Polyfuses.

The Cart Power II's seven, 4-pin female XLR output connectors provide 12Vdc. You can either connect the PSC Cart Power II to any 12V battery pack and use it as a power distribution network or plug it into AC and use it as an AC power supply. Both functions can also be used at the same time to create a un-interuptable power supply. You will primarily be operating off of AC, but if the AC goes out, the Cart Power II will automatically power your equipment from your battery. Please note that the Cart Power II does not provide a charge function for your batteries.

  • AC Input Power: 90 to 264Vac, 47 to 63Hz
  • DC Output Voltage: 13.8Vdc (when operating ion AC)
  • DC Input Power: LiFE, Li-ion, SLA batteries, 12Vdc Nominal
  • DC Input Connector: SpeakOn, 2 pole
  • Individual Output Current: 3 Amps
  • Global Output Current: 10 Amps
  • Output Connector: 4-Pin Female XLR
  • Output Pin-outs: Pin 1 Negative (-); Pin 4 Positive (+)
  • Size: 8.5 x 5.5 x 1.75 in | 21.6 x 14 x 4.4 cm
  • Weight: 2.2 lbs |1 Kg
